TOPODRONE DJI Mavic 2 Pro PPK Upgrade Kit

Upgrade kit with dual-frequency L1/L2 GNSS RTK/PPK receiver for DJI Mavic drone lineup.

Description and benefits

  • Automatic vertical takeoff and landing, automatic shooting
  • High resolution images thanks to modern Sony RX1R, RX1RII, A7R III cameras
  • Dual-frequency L1 / L2 GNSS RTK / PPK receiver on board
  • Accuracy up to 3 cm in x, y, z in post-processing without using reference points
  • Cross-platform management software (Windows, Linux, Mac OS, iOS, Android)
  • Planning and launching missions in offline mode, taking into account the terrain and the possibility of loading maps
  • Photogrammetric Product Support: Agisoft Metashape, Pix4Dmapper, Bentley Context Capture

Equipment set

  • Vertical take-off and landing aircraft Topodrone VTOL L1 / L2 RTK / PPK
  • Dual-frequency geodetic L1 / L2 GNSS RTK / PPK receiver
  • Remote control (laptop – optional, sold separately)
  • Battery
  • Charger (up to 5A)
  • Additional set of propellers
  • Shipping case
  • Software for post-processing of GNSS measurements and image geotagging
  • Instructions for work

The use of geodetic drone

A modern tool for performing high-precision geodetic aerial photography and topographic and geodetic works – integrated automated solutions based on multi-rotor and aircraft-type geodetic unmanned vehicles.

TOPODRONE solutions:

  • They do not require serious piloting skills – all flights are carried out automatically on pre-built missions.
  • There is no need to establish and coordinate ground control points – you save time and money when carrying out field work.
  • The antenna is located above the center of photography, and also uses the data of the onboard inertial navigation system to take into account the tilt of the antenna during the flight of the drone – this allows for increased accuracy compared to similar solutions on the market

Geodetic GNSS RTK / PPK receivers capabilities

All proposed solutions are equipped with professional geodetic RTK / PPK GNSS receivers of two types:

  • Single-frequency L1 GNSS RTK / PPK receiver with 72 channels
  • Dual-frequency L1 / L2 GNSS RTK / PPK receiver with 186 channels

RTK / PPK GNSS receivers:

  • Support satellite systems GPS / QZSS, GLONASS, BeiDou, Galileo, SBAS
  • Have the ability to work in RTK mode, as well as in a more accurate mode for topographic and geodetic surveys of PPK
  • Determine the coordinates of the centers of photographing with centimeter accuracy
  • Ensures the accuracy of building digital terrain models and orthophotoplans up to 3 cm in x, y, z without using reference points

Specification

Accuracy of x, y, z data2-4 cm
GNSS receiver typeL1/L2 GNSS RTK/PPK
Number of channels186
Supported SatellitesGPS, GLONASS, BeiDou, Galileo, SBAS
Country of OriginChina
Warranty, month12 months
