Carbomap ready to map the world with advanced LiDAR on a fixed wing platform


Carbomap, an environmental survey company, in collaboration with high performance LiDAR manufacturer RIEGL, UAVE and The University of Edinburgh, today announced the first successful demonstration flight of a RIEGL VUX-1LR survey-grade waveform laser scanner on a fixed wing, long range unmanned aerial vehicle (UAV). This is likely the first time that such a high-performance scanner has ever flown on a fixed wing UAV with such an advanced specification for long duration (8 hrs) and long range (1,000 km).

With centimetre-scale 3-dimensional accuracy, this breakthrough development will greatly increase the worldwide accessibility to high quality laser scanning (known as LiDAR). Throughout the world, LiDAR data is used for mapping infrastructure, conducting forest inventory, and determining flood risk in river basins, for example. However, obtaining such high quality 3D data can be very expensive to obtain using conventional airborne surveys. It is difficult to process without specialised software, and as a consequence, it is rarely available in most developing nations. By bringing such instruments together into a single UAV system (named Forest-Lux or F-Lux, for short), together with its own solution-focused software, it is now possible to get a system that can be a local asset, under local stakeholder control, and be operated at an affordable price in any country in the world.

Prof Iain Woodhouse, CEO of Carbomap, explained the breakthrough: “When every forest country in the World has two or more, F-Lux systems, all locally operated at local rates, in local stakeholder control, and ready to fly at short notice, then sub-metre elevation data will become accessible to everyone, worldwide, at a fraction of todays costs.”

F-Lux is the result of a successful cooperation between Carbomap Ltd (Scotland), Riegl Laser Measurement Systems GmbH (Austria), UAVE Ltd (Wales), and the University of Edinburgh. The development was also supported by the Forestry Commission (UK) and Scottish Enterprise.

The results of the test flight (see the images and video below) demonstrate the quality of the data that can be collected by the F-Lux. The test flights were flown by UAVE at West Wales Airport.

high resolution versions are available at

If you are interested in conducting a demonstration project, or just want to learn more about what the F-Lux can do, please get in touch at [email protected] or call us on +44(0)7887 551 724.
