HEF 32 a conventional drone helicopter platform

HEF 32 a conventional drone helicopter platform

The HEF 32 is an unmanned helicopter with a two-blade single rotor. Because of its size, weight and capabilities, it creates a class of its own and brings industrial reliability into the lightweight UAV market for the very first time.

Its strength lies in the fact that it weighs less than 25 kg and it will fit in any small van or estate car without any prior disassembly, while still being able to easily outperform all-electric competitors. It offers flight times up to 4.5 hours even when carrying modest payloads. It never needs a recharge, which means that except for some short refuelling stops, the mission can always continue. The system operates fully automatic and through nearly all weather conditions. Manned helicopter aviation finally found its first true competitor.


The HEF 32 design was created in 3D and 2D CAD and is under control of an extensive Part Data Management System. High Eye outsources the component production to its partners, but keeps the assembly in house. The frame of the helicopter follows a modular layout and is constructed from a mix of carbon fibre and aluminium alloy, while the monocoque fuselage, tail boom and landing gear have been made solely out of carbon fibre. All aluminium parts, including the rotor head, tail rotor and transmission, have been surface treated to reduce corrosion while operating in maritime environments.

The propulsion is provided by a 32cc two-stroke petrol engine, which drives the rotors via a maintenance-free, industrial quality, belt-driven transmission. Fuel is supplied via three integral tanks and a simple gravity-feed system. A brushless alternator provides continuous electrical power to all onboard systems, including the payload. A backup battery provides power in emergency situations and when the UAV is on the ground, with the engine switched off.

A mil-spec external connector allows an operator to provide external power, without having to open the system. The entire electrical system is EMC-shielded and thoroughly protected against water ingestion. The main rotor, tail rotor and throttle are operated by industrial Volz servo actuators. All flight control linkages utilise maintenance-free IGUS connections. Many ball raced-bearings have been designed out of the system or have been replaced by long-lasting friction bearings.


A clever combination of well-proven combustion technology, modern lightweight materials and aerodynamic design, give the HEF 32 the kind of performance that one would expect from a product which complies with these quality standards. High Eye designed the HEF 32 for a maximum take-off weight of 21 kg. At these weights, it can safely lift 5 kg payloads, without affecting the rest of the performance and manoeuvrability.Tabel performance figures nieuw

Naturally, the flight endurance of a helicopter depends on the type of mission. Moving forward at pre-defined speeds can vastly reduce fuel consumptions and increase the endurance even further. When flying at the speed for maximum endurance, the HEF 32 will fly beyond 4.5 hours with a payload of 2 kg, without refuelling. In hover, it will easily fly 3 hours, while only using 5 litres of petrol. Of course, the HEF 32 can also fly faster. It is currently limited to 70 knots, which equals 130 km/h. Because of a safe excess of power, it can fly comparatively high, and altitudes in excess of 6000 feet offer no problem for the system.


A multifunctional and clever autopilot serves as the brain of the HEF 32. Following a long cooperation with UAVNavigation, High Eye integrates their autopilot system. It provides all automatic, stabilising and autonomous functionalities one expects from an industrial autopilot. The HEF 32 can take-off and land fully automatic, without any pilot interference. It can safely navigate through different airspace classes via an unlimited waypoint mode. The operator can also revert to simpler modes and take direct control of the HEF 32 via a basic hover mode. Naturally, the system has been designed to be redundant, and the autopilot will always continue to stabilise the HEF 32, even after multiple sensor failures.

DSC_8431 smal (2)

The datalink is supplied by Persistent Systems and provides an encrypted IP link, which is used for the telemetry, flight controls and the payload. The system can be provided in many different frequency bands, and output strengths can be tuned to local regulatory requirements. With the normal antenna system, as supplied with the HEF 32, the datalink range exceeds 15 km with live streaming video. A tracking antenna can be supplied as an off-the-shelf upgrade, which easily increases the range beyond 50 km.


High Eye believes that a UAV should be safe to operate under nearly all circumstances that operators can run into, throughout the year. Therefore, the HEF 32 has been designed to be completely waterproof, including all electronics and flight controls. This level of protection brought the HEF 32 up to a rating which is comparable to the industrial IP 56 standard for environmental protection. The external flight control sensors are equipped with sump tanks to drain any ingested water. The main rotor and tail rotor blades feature extensive abrasion protected leading edges, which means that the HEF 32 can be operated through adverse weather conditions, rain, light hail and even light dust storms. The HEF 32 is truly an ALL-WEATHER machine.

High Eye went a step further and integrated many additional corrosion protection measures. All metal surfaces, including the transmission, rotor heads, flight controls and frame parts have been surface treated. All fasteners, nuts and bolts have been designed to reduce the chance of contact corrosion. All electrical connectors, seals and flight control actuators are rated for long-lasting operations in saltwater environments. All bearings are protected by rubber seals or have been replaced by industrial plastic friction bearings.



The HEF 32 is supplied with a thorough set of documentation. An extensive Operations Manual is used as the leading document for all operations, crew training and certifications. This manual has been written by commercially certified pilots and follows the exact same layout and terminology as can be found in manned aviation. It includes everything from extensive technical documentation to standard operational procedures and emergency checklists.


Equally as complete is the maintenance documentation. High Eye supplies the HEF 32 with full Part 145 compliant Maintenance Manuals and Illustrated Parts Breakdowns. This means that all maintenance work can be outsourced to existing approved maintenance organisations. High Eye intends to attract international maintenance organisations, to supply safe and traceable maintenance of its HEF 32 systems on a global level.High Eye works with 50-hour inspections, annual inspections and 200-hour overhauls. Because HEF 32 parts are much more affordable than parts from manned aviation, many critical parts are quite simply replaced for factory-new parts after 200 hours, instead of having them overhauled. This provides a truly cost-effective, continuous and safe maintenance solution for international operators.



What kind of application suits the HEF 32 completely depends on the combination of the helicopter and its payload. The HEF 32 is supplied with a large multifunctional payload mount, which allows the integration of even larger odd-sized payloads. Irrespectively if it is a gimbal with HD daylight video and IR video, a multispectral sensor, a directional acoustic sensor or even a lightweight, portable radar installation, the HEF 32 can carry them through a wide range of missions and environments.

With its live HD video feed, the HEF 32 can be the ideal surveillance and patrolling solution. Both long range inspections and border protection in adverse terrains can be tackled with ease. With multispectral sensors, the HEF 32 takes on a different profile and can easily be an ideal agricultural tool for large-sized farms.

Even if you have a demanding application or you have to work your way through hot and high conditions in large unmapped environments, the HEF 32 is the solution for your mission.

Download the HEF 32 brochure HERE.
