Low Cost Gorgon Stare

The slightly myopic Gorgon Stare sensor package that is being rolled out in the Predator fleet has a low cost competitor.

Once manufacturing has been resolved this system has the ability to become a major tool in emergency situations. Use a catapult to launch it and an operator with very little training can generate panoramic imagery. Swing it under a kite or balloon and things only get better.

Throw there or four up around a scene and very quickly a point cloud model of the situation could be generated to send back to Gold and Silver commanders.

In the words of Jonas Pfeil from the Technical University of Berlin

Panoramic photography creates fascinating images. Very wide angle images are closer to the human field of view than conventional pictures. If seen through a panoramic viewer they let us experience a location as if we were there. Panoramic image stitching can create panoramas from pictures taken one after another. Unfortunately, acquiring the images takes a lot of time and moving objects may cause ghosting. It is also difficult to obtain a full spherical panorama, because the downward picture cannot be captured while the camera is mounted on the tripod.

In this work, we present a throwable panoramic camera that solves these problems. The camera is thrown into the air and captures an image at the highest point of flight – when it is hardly moving. The camera takes full spherical panoramas, requires no preparation and images are taken instantaneously. It can capture scenes with many moving objects without producing ghosting artifacts and creates unique images.

Our camera uses 36 fixed-focus 2 megapixel mobile phone camera modules. The camera modules are mounted in a robust, 3D-printed, ball-shaped enclosure that is padded with foam and handles just like a ball. Our camera contains an accelerometer which we use to measure launch acceleration. Integration lets us predict rise time to the highest point, where we trigger the exposure. After catching the ball camera, pictures are downloaded in seconds using USB and automatically shown in our spherical panoramic viewer. This lets users interactively explore a full representation of the captured environment.

We used the camera to capture full spherical panoramas at scenic spots, in a crowded city square and in the middle of a group of people taking turns in throwing the camera. Above all we found that it is a very enjoyable, playful way to take pictures.
